Molten Metal Temperature Indicator Min Therm Instrument

Short Description:

MinTherm thermo-meter is a newly designed intelligent i nstrument which adopt SOC system and 24-digitΣ/∆ A/D converting technology. The instrument can be used with Pt/Rh (Type S/R/B) and WRe (Type C/D) consumption thermocouples, to measure the molten metal temperature. It also can be used with certain industrial thermocouples, for continuous temperature measuring.

By adopting SOC system for processing, it has a much higher measuring accuracy because it can amend nonlinear effect of thermocouple and correct the zero point & full range everytime thermocouple replaced.

Send email to us Download as PDF

Product Detail

Product Tags

The Min Therm adopt wall mounting type and modularity structure with large scale digital tube, which simplifies the structure for easy installation & maintenance. Clear display can also indicate the current time when the instrument is not in the measuring status.

Micro printer and flash disk record are available if the end user needs the function, which can provide user with report printed out and record saved in flash disk automatically. Profibus-DP & rs485 ports, and the wireless transmitter are also optional.

Our company can also provide the connector with compensation cable which is used to connect the instrument and thermocouple. The size and type are available according to customer needs.

The basic configuration:

1)Power cord 1pc

2)3 colors alarm lighting 1 set

3)Plug & wire B/W instrument & alarm lighting 1pc

Application

Molten metal temperature, foundries, copper, etc.

Technical Data

Specification	S	R	B	WRe
Quick Temp-detect Range in molten steel	1200~1650℃	1200~1650℃	1200~1750℃	1200~1999℃
Quick Temp-detect Range in molten copper	1000~1650℃	1000~1650℃	1000~1750℃	1000~1999℃
Continuous Temp-detect Range	0~1650℃	0~1650℃	300~1750℃	0~1999℃
Accuracy Degree	0.2
Working Condition	Ambient temperature: 0~50℃; RH≤85%
Storage Condition	Ambient temperature: -25~70℃; RH≤95%, No condensation
Power Supply	AC 220V±10%, 50Hz±5%, consumption 50W
Installation	Wall Mounting
